Description
4MP WDR IR Eyeball AI Network Camera
-
1/1.8” 4 Megapixel progressive scan CMOS
 -
H.265 & H.264 triple-stream encoding
 -
25/30 fps @ 2688 × 1520, 50/60 fps @ 1080P (1920 × 1080)
 -
WDR (140 dB), Day/Night (ICR), 3D DNR, AWB, AGC, BLC
 -
Multiple network monitoring options: Web viewer, CMS (DSS/PSS), and DMSS
 -
2.8 mm fixed lens (optional 3.6 mm, 6.0 mm)
 -
Built-in microphone
 -
Max IR LED length: 50 m
 -
Supports Micro SD memory
 -
IP67 rated
 - Datasheet

Camera
-
Image Sensor: 1/1.8” 4MP progressive scan CMOS
 -
Effective Pixels: 2688 (H) × 1520 (V)
 -
RAM/ROM: 512 MB / 128 MB
 -
Scanning System: Progressive
 -
Electronic Shutter: Auto/Manual, 1/3 s–1/100000 s
 -
Min. Illumination: 0.002 Lux @ F1.6
 -
IR Distance: Up to 50 m (164 ft)
 -
IR Control: Auto/Manual
 -
IR LEDs: 2

Lens
-
Type: Fixed-focal
 -
Mount: Board-in
 -
Focal Length: 2.8 mm / 3.6 mm / 6.0 mm
 -
Max. Aperture: F1.6
 -
Angle of View:
-
2.8 mm: H: 113°, V: 60°
 -
3.6 mm: H: 89°, V: 48°
 -
6.0 mm: H: 56°, V: 31°

 -
 -
Aperture Type: Fixed
 -
Close Focus Distance:
-
2.8 mm: 1.3 m (4.27 ft)
 -
3.6 mm: 1.9 m (6.23 ft)
 -
6.0 mm: 3.8 m (12.47 ft)

 -

DORI Distance
-
2.8 mm: Detect 58 m, Observe 23 m, Recognize 12 m, Identify 6 m
 -
3.6 mm: Detect 72 m, Observe 29 m, Recognize 14 m, Identify 7 m
 -
6.0 mm: Detect 113 m, Observe 45 m, Recognize 23 m, Identify 11 m

PTZ
-
Pan: 0˚–360˚
 -
Tilt: 0˚–78˚
 -
Rotation: 0˚–360˚

AI Features
-
Face Detection: Supported
 -
Perimeter Protection: Tripwire, intrusion, fast moving, loitering, parking, crowd detection
 -
People Counting: Line crossing, region, queue counting (supports 4 accesses and 4 areas)
 -
Object Detection: Abandoned/Missing
 -
Heat Map: Supported

Video
-
Compression: H.265, H.264, H.264B/H.264H, MJPEG (sub-stream)
 -
Smart Codec: Supported
 -
Streams: Triple streams
 -
Resolutions: Up to 2688 × 1520
 -
Frame Rates:
-
Main: Up to 30 fps @ 2688 × 1520
 -
Sub: Up to 60 fps @ D1
 -
Third: Up to 16 fps @ 1080P

 -
 -
Bitrate Control: CBR / VBR
 -
Bitrate:
-
H.264: 32 Kbps–8192 Kbps
 -
H.265: 19 Kbps–8192 Kbps

 -
 -
Day/Night: Auto (ICR) / Color / B/W
 -
WDR: 140 dB
 -
White Balance: Auto / Natural / Street Lamp / Outdoor / Manual
 -
Gain Control: Auto / Manual
 -
Noise Reduction: 3D DNR
 -
Motion Detection: 4 zones
 -
ROI: 4 zones
 -
Smart IR / Defog / Flip / Mirror / Privacy Masking: Supported

Audio
-
Compression: G.711a, G.711Mu, G.726, AAC, G.723
 -
Microphone: Built-in

Network
-
Interface: RJ-45 (10/100 Base-T)
 -
Protocols: IPv4/IPv6, HTTP/HTTPS, TCP/UDP, RTP/RTSP, SMTP, FTP/SFTP, DHCP, DNS, QoS, NTP, ICMP, IGMP, SNMP, etc.
 -
Interoperability: ONVIF (S/G/T), CGI, Milestone, Genetec, P2P
 -
Streaming: Unicast / Multicast
 -
Max Users: 20
 -
Edge Storage: MicroSD up to 256 GB, NAS, FTP/SFTP
 -
Web Access: IE (newer than IE8), Chrome, Firefox, Safari (v12+)
 -
Software: Smart PSS, DSS, DMSS
 -
Mobile: iOS, Android

Certifications
-
CE-LVD: EN60950-1
 -
CE-EMC: 2014/30/EU
 -
FCC: Part 15, Subpart B
 -
UL/CUL: UL60950-1, CAN/CSA C22.2

Electrical
-
Power Supply: DC 12V (±30%) / PoE (802.3af Class 0)
 -
Power Consumption: <7.2W

Environmental
-
Operating Temp: -30°C to +60°C (-22°F to +140°F)
 -
Humidity: < 95% RH
 -
Storage Temp: -30°C to +60°C
 -
Protection: IP67

Construction
-
Casing: Metal
 -
Dimensions: Φ106 × 99.2 mm (4.17” × 3.91”)
 -
Net Weight: 0.55 kg (1.21 lb)
 -
Gross Weight: 0.71 kg (1.57 lb)
