Description
Key Features
• 8MP Ultra HD Resolution – 3840 × 2160 video at up to 30fps
• Smart Dual Illumination – IR night vision + warm light full-colour recording
• Active Deterrence – built-in siren and red/blue warning lights
• AI Perimeter Protection – intrusion and tripwire detection with human & vehicle classification
• Smart Motion Detection (SMD 3.0) – reduces false alarms from animals or objects
• Built-in Microphones & Speaker – supports two-way audio
• MicroSD Storage – supports up to 256GB local recording
• WDR 120dB – clear images in challenging lighting conditions
• IP67 Weatherproof Housing – suitable for outdoor environments
• Flexible Power Options – PoE (802.3af) or 12V DC
Smart AI Functions
Active Deterrence
When a perimeter event occurs, the camera triggers flashing red & blue lights and an audible alarm to warn intruders.
Smart Dual Illuminators
The camera normally uses IR night vision. When motion is detected, the warm light activates for full-colour recording and clearer identification.
Perimeter Protection
Supports intelligent detection including:
• Intrusion detection
• Tripwire detection
• Human and vehicle classification
Smart Motion Detection (SMD 3.0)
Accurately filters non-relevant motion such as rain, leaves, or animals.
Camera Specifications
Camera
• Image Sensor: 1/2.8" CMOS
• Max Resolution: 3840 × 2160 (8MP)
• Electronic Shutter: 1/3s – 1/100,000s
• Minimum Illumination:
• 0.004 lux (Colour)
• 0.0004 lux (B/W)
• 0 lux with illumination
Lens
• Lens Type: Fixed focal
• Focal Length Options: 2.8mm / 3.6mm
• Lens Mount: M12
Field of View
2.8mm
• Horizontal: 106°
• Vertical: 55°
• Diagonal: 125°
3.6mm
• Horizontal: 85°
• Vertical: 45°
• Diagonal: 100°
Illumination
• IR Distance: 30m
• Warm Light Distance: 30m
• Smart illumination auto switching
Video
• Compression: H.265 / H.264 / MJPEG
• Smart Codec: Smart H.265+ / H.264+
• Streams: 3 streams supported
• Frame Rate: Up to 30fps at 8MP
AI & Detection
• Perimeter Protection (Tripwire, Intrusion)
• Human & Vehicle classification
• Smart Motion Detection SMD 3.0
• Scene change detection
• Audio detection
Audio & Alarm
• Built-in dual microphones
• Built-in speaker
• Two-way audio support
• Alarm Input: 1
• Alarm Output: 1
Storage & Network
• MicroSD support: up to 256GB
• Network Port: RJ-45 (10/100 Mbps)
• ONVIF compatibility (Profile S/G/T)
• Compatible with Smart PSS, DSS and DMSS mobile app
Power
• Power Supply: 12V DC or PoE (802.3af)
• Max Power Consumption:
• 8.6W (DC)
• 11W (PoE)
Environmental
• Weather Rating: IP67
• Operating Temperature: -40°C to +60°C
Physical
• Material: Metal + Plastic
• Dimensions: 288.4 × 94.4 × 84.7 mm
• Weight: 1.0 kg
Optional Accessories
• PFA135 Junction Box
• PFA130-E Junction Box
• PFA152-E Pole Mount Bracket
• PFM321D 12V Power Adapter
• TF-P100 MicroSD Card
