Description
IP Villa Outdoor Station & Indoor Monitor
IP Villa Door Station
-
Anodized aluminum front panel
-
2MP CMOS low illumination HD camera with 140° wide-angle view
-
Video intercom function
-
Access control function supporting two locks
-
Remote communication and unlocking via mobile app
-
Surface mount and flush mount options
-
Power over Ethernet (PoE)
-
Protection rating: IK07 & IP65
IP Indoor Monitor
-
7" TFT capacitive touch screen (1024 × 600 resolution)
-
6 alarm inputs and 1 alarm output
-
Standard PoE supported
-
Supports outdoor station and IPC monitoring
-
H.265 and H.264 video decoding
-
High performance and cost-effective
Switch
-
Ports 1–4: 4 × RJ-45 10/100 Mbps (PoE)
-
Port 5: 1 × RJ-45 10/100 Mbps (uplink)
-
Supports guide rail mounting
DHI-VTO2201F-P IP Villa Door Station
System
-
Main Processor: Embedded processor
-
Operating System: Embedded Linux
-
Button Type: Mechanical
-
Interoperability: ONVIF, CGI
-
Network Protocols: RTSP, RTMP, HTTP/HTTPS, DNS, UPnP, RTP, SIP, SSH, ONVIF, P2P
Camera & Video
-
Image Sensor: 1/2.9" 2MP CMOS low illumination HD colorful camera
-
Field of View: Horizontal 140°, Vertical 79.6°, Diagonal 159°
-
Focal Length: 2.0 mm
-
WDR: 120 dB
-
Noise Reduction: 3D DNR
-
Video Compression: H.265
-
Resolution:
-
50Hz: Main Stream 720P@25 fps, Sub Stream 1080P@25 fps
-
60Hz: Main Stream 720P@30 fps, Sub Stream 1080P@30 fps
-
-
Frame Rate: 25 fps
-
Bit Rate: 256 Kbps to 8 Mbps
-
Light Compensation: Auto IR
-
Day/Night: Auto (ICR)
Audio
-
Compression: G.711a, G.711u, PCM
-
Input: 1 channel
-
Output: Built-in speaker
-
Mode: Two-way voice communication
-
Enhancement: Echo suppression, digital noise reduction
-
Bit Rate: 16 kHz, 16 Bit
Indicators
-
Status Indicator Lights: 3
Ports & Interfaces
-
RS485: 1
-
Alarm Output: 1
-
Power Output: 1-ch 12 VDC 100 mA
-
Exit Button: 1
-
Door Status Detection: 1
-
Lock Control: 1
-
Network Port: RJ45 10M/100M
General
-
Color: Silver
-
Power Supply: DC 24V 1A, Standard PoE
-
Power Adapter: Optional
-
Installation: Flush/surface mount
-
Certifications: CE, FCC, UL
-
Dimensions: 130 × 96 × 28.5 mm (5.12" × 3.78" × 1.12")
-
Protection: IK07, IP65
-
Operating Temperature: –30°C to +60°C (–22°F to 140°F)
-
Operating Humidity: 10%–90% RH (non-condensing)
-
Operating Altitude: 0–3000 m
-
Power Consumption: ≤ 8W
-
Net Weight: 0.35 kg (0.77 lb)
-
Gross Weight: 0.4 kg (0.88 lb)
DHI-VTH2621GW-P IP Indoor Monitor
System
-
Main Processor: Embedded processor
-
Operating System: Embedded Linux
-
Network Protocols: RTSP, RTP, SIP, DNS, SSH
-
ROM: 128 MB
-
RAM: 128 MB
-
CPU: Dual-core 1.2 GHz
Display & Audio
-
Screen: 7-inch TFT capacitive touchscreen
-
Resolution: 1024 × 600
-
Audio Compression: G.711a, G.711u, PCM
-
Audio Input: 1
-
Audio Output: Built-in speaker
-
Audio Mode: Two-way voice communication
-
Audio Enhancement: Echo suppression
-
Audio Bit Rate: 16 kHz, 16 Bit
Functions
-
Communication Mode: Full digital
-
Information Release: Supports text information from management center
-
DND Mode: Customizable do-not-disturb periods
-
Number of Extensions: 9 (villa), 4 (apartment)
Ports & Interfaces
-
Alarm Inputs: 6
-
Alarm Output: 1
-
Power Output: 12 V/200 mA
-
Doorbell Support: Yes (via alarm input)
-
Network: One 10/100 Mbps Ethernet port
-
SOS Alarm: Yes
General
-
Casing: PC + ABS
-
Color: White
-
Power Supply: 12 VDC 1A, Standard PoE (36–57 V, 0.35 A)
-
Power Adapter: Optional
-
Installation: Surface mount
-
Certifications: CE, FCC
-
Accessories: Bracket and alarm ribbon cable included
-
Dimensions: 189 × 130 × 26.9 mm (7.44" × 5.12" × 1.06")
-
Operating Temperature: –10°C to +55°C (14°F to 131°F)
-
Operating Humidity: 10%–95% RH (non-condensing)
-
Operating Altitude: ≤ 3000 m (9842.52 ft)
-
Power Consumption: ≤ 2W (standby), ≤ 6W (working)
-
Net Weight: 0.34 kg (0.74 lb)
-
Gross Weight: 0.58 kg (1.27 lb)
DH-PFS3005-4ET-36E 4-Port PoE Switch
General
-
Network Ports:
-
Port 1–4: 4 × RJ-45 10/100 Mbps (PoE)
-
Port 5: 1 × RJ-45 10/100 Mbps (uplink)
-
-
Color: Black
-
Power Supply: 100–240 VAC
-
Power Adapter: Standard
-
Certifications: CE, FCC, UL
-
Dimensions: 170 × 100 × 35 mm (6.69" × 3.94" × 1.38")
-
Operating Temperature: –10°C to +55°C (14°F to 131°F)
-
Operating Humidity: 10%–95% RH (non-condensing)
-
Operating Altitude: 0–3000 m (0–9842.52 ft)
-
Net Weight: 0.45 kg (0.99 lb)
