• Captures a large area and great details at the same time
• High quality imaging with 4 MP resolution
• Excellent low-light performance with powered-by-DarkFighter technology
• Secures an expansive area with 4× optical zoom and 16× digital zoom
• Supports WDR, HLC, BLC, 3D DNR, defog, regional exposure, regional focus
• Supports 12V DC & PoE+
• Support Human and Vehicle Detection
• Datasheet

Camera Specifications

Camera

• Image Sensor:

  • Bullet channel: 1/2.8" Progressive Scan CMOS

  • PTZ channel: 1/2.8" Progressive Scan CMOS

• Min. Illumination:

  • Bullet channel: Color: 0.01 Lux @ (F1.6, AGC ON); B/W: 0.005 Lux @ (F1.6, AGC ON), 0 Lux with IR

  • PTZ channel: Color: 0.01 Lux @ (F1.5, AGC ON); B/W: 0.005 Lux @ (F1.5, AGC ON), 0 Lux with IR

• Shutter Speed: 1 s to 1/30,000 s

• Slow Shutter: Yes

• Day & Night: ICR

• Zoom:

  • PTZ channel: 4× optical, 16× digital

• Max. Resolution:

  • Bullet channel: 2560 × 1440

  • PTZ channel: 2560 × 1440

Lens

• Focus: Auto, Manual, Semi-auto

• Focal Length:

  • Bullet channel: 2.8 mm

  • PTZ channel: 2.8 to 12 mm (4× optical)

• Zoom Speed:

  • PTZ channel: Approx. 3.3 s

• Field of View (FOV):

  • Bullet channel: H: 114.9°, V: 62.4°, D: 130.7°

  • PTZ channel: H: 98°–34.2°, V: 52°–19.2°, D: 111°–39°

• Aperture:

  • Bullet channel: F1.6

  • PTZ channel: F1.5 to F2.9

Illuminator

• Supplement Light Type:

  • Bullet channel: Hybrid (IR and White Light)

  • PTZ channel: IR

• Smart Supplement Light: Yes

• Supplement Light Range:

  • PTZ channel IR: Up to 40 m

  • Bullet channel IR: Up to 30 m, White Light: Up to 30 m

PTZ

• Movement Range:

  • Pan: 0° to 350°

  • Tilt: Bullet channel: 7° to 17° (manual); PTZ channel: -5° to 90°

• Pan Speed: 0.1°–30°/s (configurable), Preset speed: 30°/s

• Tilt Speed: 0.1°–30°/s (configurable), Preset speed: 30°/s

• Proportional Pan: Yes

• Presets: 300

• Patrol Scan: 8 patrols (up to 32 presets each)

• Power-off Memory: Yes

• Park Action: Preset, Patrol Scan

• 3D Positioning: Yes

• PTZ Status Display: Yes

• Preset Freezing: Yes

• Scheduled Tasks: Dome reboot, preset, patrol scan, dome adjust, aux output

Video

• Region of Interest (ROI): 1 fixed region for main stream

• Main Stream:

  • Bullet & PTZ channel:

    • 50 Hz: 25 fps (2560×1440, 1920×1080, 1280×720)

    • 60 Hz: 30 fps (2560×1440, 1920×1080, 1280×720)

• Sub-Stream:

  • 50 Hz: 25 fps (640×480, 640×360)

  • 60 Hz: 30 fps (640×480, 640×360)

• Third Stream:

  • 50 Hz: 25 fps (1280×720, 640×480, 640×360)

  • 60 Hz: 30 fps (1280×720, 640×480, 640×360)

• Video Compression: H.265, H.264, MJPEG

• Video Bit Rate: 32 kbps to 16384 kbps

• H.264 Type: Main profile, Baseline profile, High profile

• H.265 Type: Main profile

• Scalable Video Coding (SVC): Yes

Audio

• Audio Compression: G.711, G.722.1, G.726, MP2L2, PCM, MP3, AAC

• Audio Bit Rate:

  • MP2L2: 32–160 kbps

  • AAC: 16, 32, 64 kbps

  • MP3: 8–160 kbps

• Audio Sampling Rate:

  • MP2L2: 16 kHz

  • AAC-LC: 16 kHz

  • PCM: 8/16 kHz

  • MP3: 8/16 kHz

• Environment Noise Filtering: Yes

Network

• API: ONVIF (Profile S, G, T), ISAPI, SDK, ISUP

• Network Storage: NAS (NFS, SMB/CIFS), ANR

• Protocols: TCP/IP, SMTP, RTSP, FTP, WebSockets, IGMP, WebSocket, QoS, RTCP, HTTPS, PPPoE, SNMP, NTP, RTP, UDP, DNS, HTTP, DHCP, Bonjour, 802.1X, IPv4/IPv6, DDNS, ICMP, UPnP

• Simultaneous Live View: 20

• Users/Hosts: 32

• Security Features: 802.1X authenticated access, MAC address binding, username/password authentication, IP filter, HTTPS encryption

• Client Software: iVMS-4200, Hik-Connect

• Web Browser Compatibility: IE8+, Chrome 31–44, Firefox 30–51, Safari 8.0+


• Settings: Sharpness, Saturation, Brightness, Contrast

• Wide Dynamic Range (WDR): 120 dB

• SNR: ≥ 52 dB

• Defog: Digital Defog

• Day/Night Switch: Day, Night, Auto, Scheduled Switch

• Image Enhancement: BLC, HLC, 3D DNR

• Privacy Mask:

  • Bullet & PTZ: 24 programmable polygon masks

• Regional Focus:

  • Bullet: No

  • PTZ: Yes

• Regional Exposure:

  • Bullet: No

  • PTZ: Yes

• Image Parameters Switch: Yes

Interface

• Ethernet Interface: RJ45, 10M/100M self-adaptive Ethernet port

• On-board Storage: Micro SD/SDHC/SDXC (up to 512 GB)

• Reset Button: Yes

Events

• Basic Events: Motion detection, video tampering, exception, alarm input/output

• Smart Events: Line crossing detection, intrusion detection, region entrance/exit detection, audio exception

• Event Linkage:

  • Bullet & PTZ channel: Upload to FTP/NAS/Memory Card, Notify Surveillance Center, Send Email, Trigger Alarm Output, Trigger Recording, PTZ Actions (Preset, Patrol, Pattern Scan)

General

• General Functions: Mirror, Watermark, IP Address Filter, Password Protection

• Power Supply: 12 VDC, PoE+

• Operating Conditions: -30°C to 50°C (-22°F to 122°F), Humidity ≤ 95% (non-condensing)

• Demist: Heated Glass

• Material: PC

• Dimensions: 311.5 × 223.5 × 156 mm (12.26" × 8.80" × 6.14")

• Weight: Approx. 1.37 kg (3.02 lb.)

• Approvals: IP66 Standard, Surge Protection, Voltage Transient Protection
