• Captures a large area and great details at the same time
• High quality panoramic imaging with 6 MP resolution and details imaging with 4 MP
• Excellent low-light performance with powered-by-DarkFighter technology and ColorVu technology
• Secures an expansive area with 25× optical zoom and 16× digital zoom
• Expansive night view with up to 100 m IR distance & 30 m white light
• Supports 12V DC & PoE+
• Focuses on human and vehicle targets classification based on deep learning
• Datasheet



Camera Overview

Image Sensor

• Bullet Channel: 1/2.5" Progressive Scan CMOS

• PTZ Channel: 1/2.8" Progressive Scan CMOS

Maximum Resolution

• Bullet Channel: 3632 × 1632

• PTZ Channel: 2560 × 1440

Minimum Illumination

• Bullet Channel: 0.0005 Lux @ (F1.0, AGC ON); 0 Lux with light

• PTZ Channel:

  • Color: 0.005 Lux @ (F1.6, AGC ON)

  • B/W: 0.001 Lux @ (F1.6, AGC ON)

  • 0 Lux with IR

Shutter Speed

• 1 s to 1/30,000 s

Day & Night

• ICR (Infrared Cut Filter Removal)

Zoom

• PTZ Channel: 25 × optical, 16 × digital

Slow Shutter

• Yes

Lens

Focal Length

• Bullet Channel: 2.8 mm

• PTZ Channel: 4.8 to 120 mm, 25 × optical

Field of View (FOV)

• Bullet Channel:

  • Horizontal: 180±10°

  • Vertical: 80±5°

• PTZ Channel:

  • Horizontal: 55° to 2.4° (wide-tele)

  • Vertical: 33° to 1.4° (wide-tele)

  • Diagonal: 61.5° to 2.8° (wide-tele)

Focus

• Semi-auto, manual, auto

Aperture

• Bullet Channel: F1.0

• PTZ Channel: F1.6

Zoom Speed

• PTZ Channel: Approx. 3.6 s

Illuminator

Supplement Light Type

• PTZ Channel: IR

• Bullet Channel: White Light

Supplement Light Range

• PTZ Channel: Up to 100 m

• Bullet Channel: Up to 30 m

Smart Supplement Light

• Yes

PTZ (Pan/Tilt/Zoom)

Movement Range

• Pan: 360°

• Tilt: -15° to 90° (auto flip)

Pan Speed

• Configurable from 0.1° to 80°/s; preset speed: 80°/s

Tilt Speed

• Configurable from 0.1° to 80°/s; preset speed: 80°/s

Proportional Pan

• Yes

Presets

• 300

Preset Freezing

• Yes

Patrol Scan

• 8 patrols, up to 32 presets for each patrol

Pattern Scan

• 4 pattern scans

Park Action

• Preset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama scan

3D Positioning

• Yes

PTZ Status Display

• Yes

Scheduled Task

• Preset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama scan, dome reboot, dome adjust, aux output

Power-off Memory

• Yes

Video

Main Stream

• Bullet Channel:

  • 50 Hz: 25 fps (3632 × 1632, 3680 × 1656)

  • 60 Hz: 30 fps (3632 × 1632, 3680 × 1656)

• PTZ Channel:

  • 50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720)

  • 60 Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720)

Sub-Stream

• Bullet Channel:

  • 50 Hz: 25 fps (1200 × 536, 960 × 432)

  • 60 Hz: 30 fps (1200 × 536, 960 × 432)

• PTZ Channel:

  • 50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288)

  • 60 Hz: 30 fps (704 × 480, 640 × 480, 352 × 240)

Third Stream

• PTZ Channel:

  • 50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288)

  • 60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)

Video Compression

• H.265, H.264, MJPEG

Video Bit Rate

• 32 kbps to 16384 kbps

H.264 Type

• Baseline profile, main profile, high profile

H.265 Type

• Main profile

Scalable Video Coding (SVC)

• Supported for H.264 and H.265 encoding

Region of Interest (ROI)

• 8 fixed regions for each stream

Audio

Audio Compression

• G.711, G.722.1, G.726, MP2L2, PCM, AAC-LC, MP3

Audio Bit Rate

• MP2L2: 16 kHz, 32 kHz, 48 kHz

• AAC-LC: 16 kHz, 32 kHz, 48 kHz

• PCM: 8 kHz, 16 kHz, 32 kHz, 48 kHz

• MP3: 8 kHz, 16 kHz, 32 kHz, 48 kHz

Audio Sampling Rate

• MP2L2: 32 Kbps, 40 Kbps, 48 Kbps, 56 Kbps, 64 Kbps, 80 Kbps, 96 Kbps, 112 Kbps, 128 Kbps, 144 Kbps, 160 Kbps, 192 Kbps

• AAC-LC: 16 Kbps, 32 Kbps, 64 Kbps

• MP3: 8 Kbps, 16 Kbps, 24 Kbps, 32 Kbps, 40 Kbps, 48 Kbps, 56 Kbps, 64 Kbps, 80 Kbps, 96 Kbps, 112 Kbps, 128 Kbps, 160 Kbps, 192 Kbps, 224 Kbps, 256 Kbps, 320 Kbps

Environment Noise Filtering

• Yes

Network

Protocols

• IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour, WebSocket, WebSockets

Simultaneous Live View

• 20

API

• ISAPI, SDK, ISUP, ONVIF

User/Host

• 32

Security

• Authenticated username and password, MAC address binding, HTTPS encryption, 802.1X authenticated access, IP address filter

Network Storage

• NAS (NFS, SMB/CIFS), ANR

Client

• iVMS-4200, Hik-Connect

Web Browser Compatibility

• IE11+, Chrome57+, Firefox52+, Safari12+, Edge79.0.309.65+

Image Settings

• Sharpness, saturation, brightness, contrast

Day/Night Switch

• Day, night, auto, scheduled-switch

Wide Dynamic Range (WDR)

• 120 dB

Signal-to-Noise Ratio (SNR)

• ≥ 52 dB

Defog

• Digital defog

Image Stabilization

• EIS

Image Enhancement

• BLC, HLC, 3D DNR

Privacy Mask

• Bullet Channel: 8 programmable polygon privacy masks

• PTZ Channel: 24 programmable polygon privacy masks (mask color or mosaic configurable)

Regional Focus

• Yes

Regional Exposure

• Yes

Interface

Ethernet Interface

• RJ45, self-adaptive 10M/100M Ethernet port

On-board Storage

• Built-in memory card slot, supports Micro SD/Micro SDHC/Micro SDXC, up to 256 GB

Audio

• 1 audio input, 2.0 to 2.4Vp-p, 1k Ohm±10%

• 1 audio output, line level, impedance: 600 Ω

Alarm

• 1 alarm input, 1 alarm output

Reset

• Yes

Event Detection

Basic Events

• PTZ Channel: Motion detection, video tampering alarm

• Bullet & PTZ Channels: Alarm input and output, exception events (IP address conflict, HDD full, illegal login, HDD error, network disconnected, abnormal reboot)

Smart Events

• Bullet & PTZ Channels: Audio exception detection, line crossing detection, intrusion detection, region entrance detection, region exiting detection

Linkage

• Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, audible warning, PTZ actions (preset, patrol scan, pattern scan)

Smart Linkage

• Panorama Linkage

Deep Learning Functions

• Face Capture: Detects up to 5 faces simultaneously, supports detecting, tracking, capturing, grading, selecting faces in motion, and outputs the best face picture

• Regional People Counting: Yes

General Specifications

Power

• 12VDC, PoE+

Dimensions

• Ø 166 mm × 375 mm (Ø 6.5" × 14.7")

Weight

• Approx. 2.4 kg (13.2 lb.)

Material

• ADC12

Operating Conditions

• Temperature: -30℃ to 65℃ (-22°F to 149°F)

• Humidity: < 90% RH

Demist

• Demist by heating the glass

Power Consumption and Current

• Max. 24 W, including Max. 2.6 W for heater and Max. 11 W for supplement light

Protection

• IP66 Standard, 6000 V Lightning Protection, Surge Protection, and Voltage Transient Protection
