Hikvision Acusense DS-2CD2366G2-IU IP Camera 6MP Turret Network Camera WHITE

• High quality imaging with 6 MP resolution
• Excellent low-light performance with powered-by-DarkFighter technology
• Efficient H.265+ compression technology
• Clear imaging against strong back light due to 120 dB true WDR technology
• Focus on human and vehicle targets classification based on deep learning
• Built-in microphone for real-time audio security(-U)
• Water and dust resistant (IP67)
• Datasheet

Camera

• Image Sensor: 1/2.4" Progressive Scan CMOS

• Max. Resolution: 3200 × 1800

• Min. Illumination:

  • Color: 0.003 Lux @ (F1.6, AGC ON)

  • B/W: 0 Lux with IR

• Shutter Time: 1/3 s to 1/100,000 s

• Day & Night: IR cut filter

• Angle Adjustment:

  • Pan: 0° to 360°

  • Tilt: 0° to 75°

  • Rotate: 0° to 360°

Lens

• Lens Type: Fixed lens, 2.8 mm / 4 mm / 6 mm optional

• Focal Length & FOV:

  • 2.8 mm: H 105°, V 55°, D 127°

  • 4 mm: H 78°, V 38°, D 96°

  • 6 mm: H 51°, V 26°, D 59°

• Lens Mount: M12

• Iris Type: Fixed

• Aperture: F1.6

DORI (Detection, Observation, Recognition, Identification)

• 2.8 mm: D: 76 m, O: 30 m, R: 15 m, I: 7 m

• 4 mm: D: 115 m, O: 45 m, R: 23 m, I: 11 m

• 6 mm: D: 164 m, O: 65 m, R: 32 m, I: 16 m

Illuminator

• Type: IR

• Range: Up to 30 m

• Smart Supplement Light: Yes

• IR Wavelength: 850 nm

Video

• Main Stream:

  • 50 Hz: 25 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)

  • 60 Hz: 30 fps (same resolutions)

• Sub-Stream:

  • 50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)

  • 60 Hz: 30 fps (same resolutions)

• Third Stream:

  • 50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)

  • 60 Hz: 10 fps (same resolutions)

  • Supported under certain settings

• Video Compression:

  • Main: H.265+/H.265/H.264+/H.264

  • Sub: H.265/H.264/MJPEG

  • Third: H.265/H.264

• Bit Rate: 32 Kbps to 16 Mbps

• Profiles: H.264 (Baseline/Main/High), H.265 (Main)

• Bit Rate Control: CBR, VBR

• SVC: H.264 & H.265 encoding

• ROI: 1 fixed region (main & sub stream)

Audio (-U Models)

• Type: Mono sound

• Compression: G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC

• Bit Rate:

  • 64 Kbps (G.711)

  • 16 Kbps (G.722.1 / G.726)

  • 32–192 Kbps (MP2L2)

  • 8–320 Kbps (MP3)

  • 16–64 Kbps (AAC-LC)

• Sampling Rate: 8 / 16 / 32 / 44.1 / 48 kHz

• Noise Filtering: Yes

Network

• Protocols: TCP/IP, HTTP/HTTPS, FTP, DHCP, DNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4/IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, ARP, WebSocket, SRTP, SFTP

• Simultaneous Live View: Up to 6 channels

• API: ONVIF (Profile S/G/T), ISAPI, SDK, ISUP

• Users: Up to 32 (Admin / Operator / User)

• Security: Password protection, HTTPS encryption, 802.1X, IP filtering, TLS 1.1–1.3, security audit log, watermark, WSSE authentication, etc.

• Storage: NAS (NFS, SMB/CIFS), ANR, memory card (encryption & health detection supported)

• Clients: iVMS-4200, Hik-Connect, Hik-Central

• Browsers:

  • Plug-in: IE 10/11

  • Plug-in free: Chrome 57+, Firefox 52+, Edge 89+


• Switch Parameters: Yes

• Adjustments: Rotate, saturation, brightness, contrast, sharpness, gain, white balance

• Day/Night Switch: Auto, Schedule, Manual

• WDR: 120 dB

• SNR: ≥ 52 dB

• Enhancements: BLC, HLC, 3D DNR

• Privacy Mask: Up to 4 regions

Interface

• Ethernet: 1 × RJ45 10/100 Mbps

• On-board Storage: microSD/SDHC/SDXC up to 512 GB

• Microphone: Yes (-U models)

• Reset Key: Yes

Event

• Basic: Motion detection (human/vehicle), video tampering, exceptions

• Smart: Line crossing, intrusion, region entrance/exit, scene change (human/vehicle filtering)

• Linkage: Upload to FTP/NAS/SD, email, notify center, recording, snapshot

• Deep Learning: Face capture

General

• Power:

  • 12 VDC ± 25% (0.45 A, max. 5.4 W)

  • PoE: IEEE 802.3af, Class 3, max. 6.5 W

• Material: Metal (except trim ring)

• Dimensions: Ø138.3 × 111.4 mm (Ø5.4" × 4.4")

• Package: 170 × 170 × 150 mm (6.7" × 6.7" × 5.9")

• Weight: 740 g (1.6 lb) / With package: 1070 g (2.4 lb)

• Operating & Storage: -30 °C to 60 °C, ≤ 95% RH (non-condensing)

• Languages: 33 supported (EN, DE, FR, ES, PT, RU, ZH, JA, etc.)

• Functions: Heartbeat, mirror, flash log, pixel counter, anti-flicker, password reset via email

Approvals & Protection

• EMC: CE-EMC, RCM, KC

• Safety: UL, CB, CE-LVD

• Environment: CE-RoHS, WEEE, REACH

• Protection: IP67
