Description
Key Features
- 4 MP resolution for clear, detailed video
- Powered-by-DarkFighter technology for excellent low-light performance
- AcuSense deep learning human and vehicle classification
- Built-in strobe light and audible warning deterrent
- 120 dB True WDR for challenging lighting conditions
- Efficient H.265+ video compression
- Up to 80 m IR night vision
- IP67 weatherproof protection
- Full metal housing for enhanced durability
- Supports microSD storage up to 128 GB
Camera
Image Sensor: 1/2.7" Progressive Scan CMOS
Maximum Resolution: 2688 × 1520
Minimum Illumination: Color: 0.012 Lux @ F1.6 (AGC ON), 0 Lux with IR
Shutter Speed: 1/3 s to 1/100,000 s
Slow Shutter: Yes
Day/Night: IR Cut Filter
Wide Dynamic Range: 120 dB True WDR
Angle Adjustment: Pan 0° to 360°, Tilt 0° to 90°, Rotate 0° to 360°
Lens
Lens Type: Fixed
Lens Options: 2.8 mm / 4 mm
Aperture: F1.6
Lens Mount: M12
Aperture Type: Fixed
Field of View
2.8 mm: Horizontal 104°, Vertical 58°, Diagonal 124°
4 mm: Horizontal 83°, Vertical 44°, Diagonal 99°
Lighting
IR Range: Up to 80 m
IR Wavelength: 850 nm
Video
Maximum Resolution: 2688 × 1520
Main Stream: Up to 2688 × 1520 @ 25 fps (50 Hz) / 30 fps (60 Hz)
Sub Stream: Up to 704 × 576 @ 25 fps (50 Hz) / 30 fps (60 Hz)
Video Compression: H.265, H.264, MJPEG
Smart Codec: H.265+, H.264+
Video Bit Rate: 32 Kbps to 16 Mbps
Scalable Video Coding (SVC): Supported for H.264 and H.265
ROI: Up to 4 fixed regions for main and sub streams
Audio & Deterrence
Audible Warning: Built-in audio alarm
Visual Warning: Built-in strobe light
AI Analytics
AcuSense Classification: Human and Vehicle Detection
Line Crossing Detection: Supported
Intrusion Detection: Supported
Region Entrance Detection: Supported
Region Exit Detection: Supported
False Alarm Filtering: Human and Vehicle Classification Based
Network & Storage
Simultaneous Live View: Up to 6 Channels
Network Protocols: TCP/IP, HTTP, HTTPS, DHCP, DNS, DDNS, RTSP, RTP, NTP, SMTP, SNMP, IPv6, UPnP, QoS and more
API: ONVIF Profile S, ONVIF Profile G, ISAPI
Users: Up to 32 Users, 3 Access Levels
Local Storage: MicroSD/SDHC/SDXC up to 128 GB
NAS Support: NFS, SMB/CIFS
ANR: Supported
Clients: Hik-Connect, iVMS-4200, iVMS-4500, iVMS-5200
Image Features
Day/Night Modes: Day, Night, Auto, Schedule
Noise Reduction: 3D DNR
Image Enhancement: BLC, HLC, 3D DNR
Adjustable Settings: Brightness, Contrast, Saturation, Sharpness, AGC, White Balance
Alarm & Events
Alarm Triggers: Motion Detection, Video Tampering, Network Disconnection, IP Conflict, Illegal Login, HDD Full, HDD Error
Smart Events: Line Crossing, Intrusion, Region Entrance, Region Exit, Human & Vehicle Classification
Interfaces
Ethernet Port: 1 × RJ45 10/100 Mbps Self-Adaptive Port
On-board Storage: microSD Slot up to 128 GB
Hardware Reset: Supported
Power
Power Supply: 12 VDC ±25% or PoE (802.3at, Class 4)
Power Consumption: Max. 15 W (12 VDC), Max. 18 W (PoE)
Build
Housing Material: Full Metal Construction
Dimensions: Φ105 × 292.2 mm
Weight: 1320 g
Protection
Weather Rating: IP67
Operating Temperature: -30°C to +60°C
Operating Humidity: Up to 95% (Non-Condensing)
General Functions
Features: One-Key Reset, Anti-Flicker, Heartbeat, Mirror, Password Protection, Privacy Mask, Watermark, IP Address Filter
Certifications
Protection Rating: IP67
