Key Features
• CAT6 U/UTP network cable for data and PoE transmission
• Stable electrical performance compliant with ANSI/TIA-568.2-D, IEC61156, ISO/IEC11801
• Strong outer sheath with high tensile and compressive strength for better protection during installation
• Passes Fluke 90 m permanent link test at 50°C continuous operation
• Passes Fluke 100 m channel test with 57 V / 1 A PoE load
• Solid bare copper conductor for lower resistance and improved signal transmission
• RoHS 2.0 compliant
Datasheet
General
• Cable category: Cat6
• Cable structure: U/UTP
• Fire resistance rating: CPR Fca
• Usage: Indoor
Conductor
• Conductor material: Solid bare copper
• Conductor diameter: 0.50 ± 0.01 mm (24 AWG)
Insulation
• Insulation diameter: 0.88 ± 0.05 mm
Sheath
• Sheath material: PVC
• Sheath color: Grey
Cable Structure
• Cable length: 305 ± 1.5 m
• Rip cord: Yes
• Separator: Yes
