• HikAI-ISP for excellant noise reduction effect
• 24/7 colorful imaging via ColorVu technology
• Scene-adaptive WDR
• Focus on Person and Vehicle classification based on deep learning
• Built-in arrayed dual-microphone for real-time high quality audio security
• Provide real-time security via built-in two-way audio
• Anti-corrosion design, providing reliability and longevity compared to standard (NEMA4X)
• Smart Hybrid Light: Integrates IR and White lights, 3 supplemental lighting modes
• Audio and alarm interface available
• Water and dust resistant (IP67)
• Active strobe light and audio alarm to warn intruders off
• Datasheet

Camera

Image Sensor: 1/1.8" Progressive Scan CMOS
Max. Resolution: 3200 × 1800
Min. Illumination:

• Color: 0.0005 Lux @ (F1.0, AGC ON)

• 0 Lux with light

Shutter Time: 1 s to 1/100,000 s
Day & Night: IR Cut Filter

Angle Adjustment:

• Pan: 0° to 360°

• Tilt: 0° to 90°

• Rotate: 0° to 360°

---

Lens

Lens Type: Fixed focal lens (2.8 mm / 4 mm optional)

Focal Length & Field of View

2.8 mm

• Horizontal FOV: 108.8°

• Vertical FOV: 56.4°

• Diagonal FOV: 134.3°

4 mm

• Horizontal FOV: 93.3°

• Vertical FOV: 47.2°

• Diagonal FOV: 114.2°

Lens Mount: M16
Iris Type: Fixed
Aperture: F1.0

Depth of Field

• 2.8 mm: 3.3 m to ∞

• 4 mm: 3.8 m to ∞

---

DORI Distance

2.8 mm

• Detect: 89 m

• Observe: 35 m

• Recognize: 17 m

• Identify: 8 m

4 mm

• Detect: 109 m

• Observe: 43 m

• Recognize: 21 m

• Identify: 10 m

---

Illuminator

Supplement Light Type: White Light / IR
Supplement Light Range: Up to 60 m
Smart Supplement Light: Yes
IR Wavelength: 850 nm

---

Video

Main Stream

50 Hz

• 25 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)

60 Hz

• 30 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)

Sub Stream

50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)
60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)

Third Stream*

50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)

Third stream supported under certain settings.

Video Compression

• Main Stream: H.265 / H.264 / H.264+ / H.265+

• Sub Stream: H.265 / H.264 / MJPEG

• Third Stream: H.265 / H.264

Video Bit Rate: 32 Kbps to 16 Mbps

H.264 Type: Baseline Profile / Main Profile / High Profile
H.265 Type: Main Profile

Bit Rate Control: CBR / VBR

Scalable Video Coding: H.264 / H.265

ROI: 1 fixed region for main stream

---

Audio

Audio Type: Mono sound

Audio Compression:
G.711 / G.722.1 / G.726 / MP2L2 / PCM / MP3 / AAC-LC

Audio Bit Rate:

• 64 Kbps (G.711ulaw / G.711alaw)

• 16 Kbps (G.722.1 / G.726)

• 32–192 Kbps (MP2L2)

• 8–320 Kbps (MP3)

• 16–64 Kbps (AAC-LC)

Audio Sampling Rate:
8 / 16 / 32 / 48 kHz

Environment Noise Filtering: Yes

---

Network

Protocols:
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets, SRTP, SFTP

Simultaneous Live View: Up to 6 channels

API:
ONVIF (Profile S, T, G), ISAPI, SDK, ISUP

User Access:
Up to 32 users
User levels: Administrator / Operator / User

---

Security

• Password protection

• Complex password support

• HTTPS encryption

• 802.1X authentication

• IP address filtering

• HTTP/HTTPS digest authentication

• WSSE authentication

• Security audit log

• TLS 1.1 / 1.2 / 1.3

• MAC address authentication

---

Storage & Client

Network Storage: NAS (NFS, SMB/CIFS), ANR

Client Software:
iVMS-4200, Hik-Connect, Hik-Central

Web Browser Support:
Chrome 80+, Firefox 80+, Edge 89+ (plug-in free live view)

---


Image Parameters Switch: Yes

Image Settings:
Rotate, saturation, brightness, contrast, sharpness, gain, white balance

Day/Night Mode: Day / Night / Auto / Schedule

Image Enhancement:
BLC, HLC, 3D DNR, Distortion Correction, Defog

SNR: ≥ 52 dB

Wide Dynamic Range: 130 dB

Image Stabilization: EIS

Privacy Mask: 4 programmable polygon masks

---

Interface

Ethernet: 1 × RJ45 (10/100 Mbps)

Onboard Storage:
MicroSD / microSDHC / microSDXC up to 512 GB

Built-in Speaker:

• Max Power: 2 W

• Sound Pressure Level: 120 dB @ 10 cm

Built-in Microphone: Dual array microphone

Audio I/O:

• 1 input (line in)

• 1 output (line out)

Alarm Interface:
2 input / 2 output (24 VDC/24 VAC, 1 A)

Reset Key: Yes

---

Event

Basic Events

• Motion detection (human/vehicle filtering)

• Video tampering

• Exception alarms

Smart Events

• Scene change detection

Linkage Actions

• Upload to FTP / NAS / memory card

• Email notification

• Alarm output

• Recording

• Snapshot capture

• Audible warning

• Strobe light

---

AI Functions

Face Capture: Yes

Perimeter Protection

• Line crossing

• Intrusion

• Region entrance

• Region exit

Supports human and vehicle classification.

---

General

Power Supply:
12 VDC ±25%, 1.41 A (max. 17 W)

PoE: IEEE 802.3at (Class 4, max. 18 W)

Material:
Front cover: Metal
Body: Metal
Bracket: Metal

Dimensions:
286.7 × 93.3 × 91.2 mm

Weight:
Approx. 1250 g

Package Weight:
Approx. 1800 g

---

Environment

Operating Temperature:
-30 °C to 60 °C

Humidity:
≤ 95% (non-condensing)

Protection Rating:
IP67

Anti-Corrosion:
NEMA 4X

---

Certification

EMC: CE, RCM, IC, KC
Safety: UL 62368-1, IEC 62368-1
Environment: RoHS
