Description
Key Features
• 8 MP high resolution imaging
• Darkfighter 2.0 technology for 24/7 full color imaging
• HIK AI-ISP for advanced noise reduction
• Smart Hybrid Light with IR and white light modes
• Built-in strobe light and audible warning for active deterrence
• Person and vehicle classification using deep learning
• Built-in array dual microphones for high quality audio
• Two-way audio with built-in speaker
• Scene adaptive WDR for challenging lighting conditions
• Anti-corrosion version (-Y) with NEMA4X protection
• IP67 weatherproof and IK10 vandal resistant
Camera
• Image sensor: 1/1.8" Progressive Scan CMOS
• Maximum resolution: 3840 × 2160 (8 MP)
• Minimum illumination:
• Color: 0.001 Lux @ F1.2
• 0 Lux with light
• Shutter speed: 1 s – 1/100,000 s
• Day/Night: IR cut filter
• Angle adjustment:
• Pan: 0° to 355°
• Tilt: 0° to 90°
• Rotation: 0° to 360°
Lens
• Lens type: Motorized varifocal
• Focal length: 2.7 mm – 13.5 mm
• Horizontal FOV: 112.3° – 41.2°
• Vertical FOV: 58.1° – 23.1°
• Diagonal FOV: 137.4° – 47.3°
• Aperture: F1.2
• Iris type: Auto iris
• Depth of field: 1 m to ∞
DORI Distance
• Wide lens:
• Detect: 89.2 m
• Observe: 35.4 m
• Recognize: 17.8 m
• Identify: 8.9 m
• Tele lens:
• Detect: 220 m
• Observe: 87.3 m
• Recognize: 44 m
• Identify: 22 m
Illuminator
• Supplement light: IR + White Light
• Light range: Up to 60 m
• IR wavelength: 850 nm
• Smart supplement light: Supported
HEOP Open Platform
• Open platform: HEOP 2.0 OpenDev SDK
• Memory:
• 40 MB memory
• 450 MB smart RAM
• 2 GB eMMC
• Computing power: 1.5 TOPS
• Supported AI frameworks:
• Caffe
• PyTorch
• TensorFlow
• PaddlePaddle
• ONNX
• Programming language: C / C++
Video
• Main stream:
• Up to 3840 × 2160 @ 25/30 fps
• Sub stream:
• Up to 1280 × 720 @ 25/30 fps
• Third stream:
• Up to 1280 × 720 @ 10 fps
• Fourth stream:
• 1 fps low bandwidth stream
• Video compression:
• H.265 / H.265+
• H.264 / H.264+
• MJPEG
• Bit rate: 32 Kbps – 16 Mbps
• Bit rate control: CBR / VBR
• ROI: 5 regions
• SVC: Supported
• e-PTZ: Patrol and auto tracking
Audio
• Built-in array dual microphones
• Built-in speaker
• Audio compression:
• G.711
• G.722.1
• G.726
• MP2L2
• PCM
• MP3
• AAC-LC
• Audio sampling rate:
• 8 / 16 / 32 / 48 kHz
• Environment noise filtering: Supported
Network
• Network interface: 1 × RJ45 10/100 Mbps
• Supported protocols include:
• TCP/IP
• HTTP / HTTPS
• FTP
• DHCP
• DNS / DDNS
• RTSP / RTP / RTCP
• NTP
• SMTP
• QoS
• IPv4 / IPv6
• SNMP
• SSL / TLS
• SRTP
• WebSocket
• Simultaneous live view: Up to 6 channels
• User access: Up to 32 users
• User levels:
• Administrator
• Operator
• User
Storage
• MicroSD slot supporting up to 512 GB
• Network storage:
• NAS (NFS / SMB)
• ANR (Auto Network Replenishment)
• WDR: 130 dB
• Image enhancements:
• BLC
• HLC
• 3D DNR
• Defog
• Distortion correction
• Image stabilization: EIS
• Privacy masking: 8 areas
• Image adjustments:
• Brightness
• Contrast
• Saturation
• Sharpness
• Gain
• White balance
Deep Learning Functions
• Face capture
• People counting
• Perimeter protection:
• Line crossing detection
• Intrusion detection
• Region entrance detection
• Region exit detection
• Target classification:
• Human
• Vehicle
Interfaces
• Ethernet: 1 × RJ45
• Alarm: 2 inputs / 2 outputs
• Audio:
• 1 input
• 1 output
• Reset button: Yes
• Power output: 12 VDC (100 mA)
Events
• Motion detection
• Video tampering detection
• Scene change detection
• Audio exception detection
• Defocus detection
• Alarm linkage:
• Recording
• Capture
• Email notification
• FTP upload
• Alarm output
• Strobe light
• Audible warning
Power
• Power supply:
• 12 VDC ±25%
• PoE:
• IEEE 802.3at
• Power consumption:
• Max 18 W (PoE)
General
• Material: Full metal housing
• Dimensions: 335 × 140 × 140 mm
• Weight: Approx. 1.55 kg
• Operating temperature:
• -30°C to +60°C
• Operating humidity: ≤ 95%
Protection
• IP67 weatherproof
• IK10 vandal resistant
• NEMA 4X anti-corrosion protection (-Y model)
Certifications
• CE-EMC
• CE-LVD
• CB
• RoHS
