Image Sensor: 8.29 Megapixel Progressive Scan CMOS
Max. Resolution: 3840 (H) × 2160 (V)
Min. Illumination:
Color: 0.003 Lux @ (F2.4, AGC ON)
0 Lux with IR
Shutter Time:
PAL: 1/12.5 s to 1/50,000 s
NTSC: 1/15 s to 1/50,000 s
Day & Night: IR Cut Filter
Angle Adjustment: Pan: 0°–360°, Tilt: 0°–90°, Rotate: 0°–360°
Signal System: PAL / NTSC
Lens Type: 2.7 mm – 13.5 mm Motorized Varifocal Lens
Focal Length & Field of View: 108.1° – 45.6°
Lens Mount: Φ14
Supplement Light Type: IR
Supplement Light Range: Up to 80 m
Smart Supplement Light: Yes
Image Settings: Brightness, Sharpness, Mirror, Smart IR, AGC
Frame Rate:
TVI: 8MP @ 12.5/15 fps, 5MP @ 20 fps, 4MP @ 25/30 fps, 2MP @ 25/30 fps
CVI: 8MP @ 12.5/15 fps
AHD: 8MP @ 12.5/15 fps
CVBS: 960H (P/N)
Day/Night Mode: Auto / Color / B&W
Wide Dynamic Range (WDR): ≥130 dB
Image Enhancement: BLC, WDR
Noise Reduction: 3D DNR
White Balance: Auto / Manual
Video Output: Switchable TVI / AHD / CVI / CVBS (1 HD analog output)
Power Supply:
9.6 VDC – 14.4 VDC
19.2 VAC – 28.8 VAC
Max Power Consumption: 10.8 W
Material: Metal
Dimensions: 84.5 × 92 × 255.1 mm (3.33" × 3.62" × 10")
Weight: Approx. 925 g (2.04 lb)
Operating Conditions: –40 °C to 60 °C (–40 °F to 140 °F), ≤90% humidity (non-condensing)
Communication: HIKVISION-C
Protection: IP67
