• Indoor Station: 7' touch screen 2-Wire IP indoor station with 1024 × 600 resolution
• Indoor Station: Convenient Hik-Connect APP Mobile Control: receive calls, open the door and live view remotely
• Indoor Station: Easy wizard for quick set up
• Indoor Station: Live-view of the door station
• Indoor Station: Support voice messages when no response from the indoor station
• Door Station: High quality imaging with 2 MP resolution
• Door Station: One call physical button for easier calls
• Door Station: Two-lock control
• Door Station: IP65 protection level
• Door Station: Directly provide 12 V, 500 mA power output for one electronic lock without additional power supply
• Door Station: High-quality stainless steel panel
• Datasheet

Door Station – System Parameters

• Operation System: Embedded Linux

• Operation Mode: Single-button

• Flash: 32 MB

• RAM: 256 MB

Door Station – Video Parameters

• Camera: 2MP HD camera

• Resolution:

  • Main stream: 1280 × 720p, 1920 × 1080p

  • Sub stream: 640 × 480

• Night Vision: Low illumination IR, supplement distance 3 m

• WDR: Supported

• Field of View: Horizontal 140°, Vertical 85°

• Video Compression Standard: H.264

Door Station – Audio Parameters

• Audio Input: Built-in omnidirectional microphone

• Audio Output: Built-in loudspeaker, 8Ω

• Audio Quality: Noise suppression & echo cancellation

• Compression Standard: G.711 U, G.711 A

• Compression Rate: 64 Kbps

Door Station – Network Parameters

• Protocols: TCP/IP, RSTP, SIP 2.0

• Wired Network: Supported, 2-wire wiring

Door Station – Device Interfaces

• RS-485: /

• Alarm Input: 2 (Exit button or door contact)

• Output: 1 × 12 V / 500 mA output

• Two-wire Interface: 1

• Tamper Switch: 1

Door Station – General

• Power Consumption: ＜ 10 W

• Working Temperature: -40 °C to +60 °C (-40 °F to 140 °F)

• Working Humidity: 10% to 95%

• Installation: Surface mounting, flush mounting

• Protection Level: IP65

• Indicator: 3

• Power Supply: From indoor station

Indoor Station – System Parameters

• Operation System: Embedded Linux

• Memory: 128 MB

• Flash: 32 MB

Indoor Station – Display Parameters

• Display Screen: 7-inch TFT touch screen

• Resolution: 1024 × 600

• Operation Method: Capacitive touch screen

• Brightness: Adjustable

Indoor Station – Audio Parameters

• Audio Input: Built-in omnidirectional microphone

• Audio Output: Built-in loudspeaker, 8Ω

• Audio Quality: Noise suppression & echo cancellation

• Volume: Locally adjustable

• Compression Standard: G.711 U, G.711 A

Indoor Station – Network Parameters

• Wired Network: 1 × 10 Mbps (via 2-wire interface)

• Wireless Network: Wi-Fi 802.11 b/g/n, 2.400–2.4835 GHz

Indoor Station – Device Interfaces

• RS-485: 1

• Alarm Input: Reserved

• Two-wire Output: 1

• Two-wire Input: 1

• Power Input: 24 VDC / 1.5 A

Indoor Station – General

• Power Supply: 24 VDC / 1.5 A

• Power Consumption: ≤ 8 W

• Working Temperature: -10 °C to 50 °C (14 °F to 122 °F)

• Working Humidity: 10% to 90%
