Description
Key Features
• Supports H.265+/H.265/H.264+/H.264 video compression
• Intelligent analytics powered by Guanlan Large-Scale AI Models
• Supports up to 32 IP camera channels
• Supports AcuSeek and AcuSearch on up to 32 channels
• Supports up to 24-ch perimeter protection
• Supports up to 16-ch facial recognition for video stream
• Supports up to 32-ch facial recognition for face picture comparison
• Supports up to 16-ch video structuralization
• Supports connection of up to 8 IP speakers
AI Analytics
• AI by NVR:
• Facial recognition
• Perimeter protection
• Video structuralization
• AcuSearch
• AcuSeek
• AI by camera:
• Facial recognition
• Perimeter protection
• Video structuralization
• AcuSearch
• Motion Detection 2.0
• ANPR
• People counting
• VCA
AI Engine
• 1 GPU engine dedicated for AcuSeek and OVD
• 2 GPU engines available for AI algorithms
• Each GPU engine can run one intelligent algorithm
• Engine modes (choose one per engine):
• Facial recognition
• Perimeter protection
• Video structuralization
• AcuSearch
• Facial recognition performance:
• 8-ch (4 MP) video capture
• 32-ch face image comparison
• Perimeter protection performance:
• 12-ch (2 MP) video analysis
• 32-ch image analysis
• Video structuralization performance:
• 8-ch (2 MP) structured analysis
• AcuSearch performance by NVR:
• 16-ch @ 2 MP
• Note: To enable AcuSeek, at least one engine must run AcuSearch mode
Facial Recognition
• Face detection and analytics:
• Face picture comparison
• Human face capture
• Face picture search
• Face picture libraries:
• Up to 32 libraries
• Up to 100,000 face pictures
• Face picture comparison:
• 32 channels
• Comparison speed: 32 pictures per second
• Facial analytics performance:
• 16-ch facial capture
• 2 MP: 8-ch
• 4 MP: 8-ch
• 8 MP: 4-ch
AcuSearch
• By camera:
• All channels supported
• Up to 600,000 targets per day
• Camera must support AcuSearch
• By NVR:
• 16-ch @ 2 MP
• 8-ch @ 4 MP
• 4-ch @ 8 MP
AcuSeek
• Supports 16-ch @ 2 MP, 8-ch @ 4 MP, 4-ch @ 8 MP
• Requires:
• 1 GPU engine for target capture
• 1 GPU engine for AcuSearch modeling
• 1 GPU engine for AcuSeek modeling
• With AcuSense cameras enabled:
• Supports all channels
• Target modeling capability:
• Up to 600,000 targets per day
• Supported search languages include:
• English
• French
• Italian
• German
• Polish
• Portuguese
• Thai
• Russian
• Arabic
• Turkish
• Spanish
Perimeter Protection
• By NVR with Large Model:
• 12-ch @ 2 MP
• 8-ch @ 4 MP
• 4-ch @ 8 MP
• Requires:
• 1 GPU engine for video analysis
• 1 GPU engine for large model secondary analysis
• Secondary analysis capability: 2 events/sec
• Without Large Model:
• 24-ch @ 2 MP
• 16-ch @ 4 MP
• 8-ch @ 8 MP
• By camera:
• All channels supported with AcuSense cameras
Video Structuralization
• Structured analysis performance:
• 16-ch @ 2 MP
• 12-ch @ 4 MP
• 6-ch @ 8 MP
ANPR
• ANPR supported by camera on all channels
• Plate attributes:
• Plate number
• License plate color
• Plate type
• Vehicle attributes:
• Vehicle brand
• Vehicle color
• Vehicle type
• Supports ANPR in Australia and many other global regions
Video and Audio
• IP video input: 32 channels
• Maximum camera resolution: 32 MP
• Incoming bandwidth: 320 Mbps
• Outgoing bandwidth: 400 Mbps
• HDMI 1 output:
• 8K (7680 × 4320) @ 30Hz
• 4K @ 60Hz / 30Hz
• 2K @ 60Hz
• 1080p @ 60Hz
• HDMI 2 output:
• 4K @ 60Hz / 30Hz
• 2K @ 60Hz
• 1080p @ 60Hz
• Note:
• When HDMI 1 is 8K, HDMI 2 maximum output is 1080p
• VGA outputs:
• 2 VGA outputs (1920 × 1080 @ 60Hz)
• Video output modes:
• HDMI1 + VGA1 simultaneous
• HDMI2 + VGA2 simultaneous
• CVBS output:
• 1-ch BNC
• Audio outputs: 2 × RCA
• Two-way audio: 1 × RCA
Decoding
• Decoding formats:
• H.265
• H.265+
• H.264
• H.264+
• Decoding capability:
• 2-ch @ 32 MP (30 fps)
• 2-ch @ 24 MP (30 fps)
• 4-ch @ 16 MP (30 fps)
• 8-ch @ 8 MP (30 fps)
• 16-ch @ 4 MP (30 fps)
• 32-ch @ 2 MP (30 fps)
• Synchronous playback: 16 channels
• Recording resolutions supported:
• 32 MP
• 24 MP
• 12 MP
• 8 MP
• 6 MP
• 5 MP
• 4 MP
• 3 MP
• 1080p
• UXGA
• 720p
• VGA
• 4CIF / DCIF / 2CIF / CIF / QCIF
Network
• Remote connection: 128 users
• Network protocols include:
• TCP/IP
• DHCP
• IPv4 / IPv6
• DNS / DDNS
• NTP
• RTSP
• SADP
• SMTP
• SNMP
• NFS
• iSCSI
• ISUP
• UPnP
• HTTP / HTTPS
• ONVIF
• OTAP
• API support:
• ONVIF Profile S / G
• SDK
• ISAPI
• Compatible browsers:
• IE11
• Chrome v57+
• Firefox v52+
• Safari v12+
• Edge v89+
• Network interfaces:
• 2 × RJ-45 10/100/1000 Mbps
RAID
• RAID types supported:
• RAID 0
• RAID 1
• RAID 5
• RAID 6
• RAID 10
Storage and Interfaces
• SATA: 8 SATA interfaces
• eSATA: 1 interface
• HDD capacity:
• Up to 20 TB per HDD
• Serial interfaces:
• 1 × RS-232
• 1 × RS-485
• USB ports:
• Front: 2 × USB 2.0
• Rear: 2 × USB 3.0
• Alarm input/output: 16 in / 9 out
• Additional outputs:
• Ctrl 12V controllable power output
• 12V DC auxiliary power output
General
• Power supply: 100–240 VAC
• Power consumption:
• ≤ 50 W (without HDD)
• Operating temperature:
• -10°C to 55°C
• Operating humidity:
• 10% to 90%
• Dimensions:
• 442 × 540 × 88 mm
• Weight:
• ≤ 8 kg (without HDD)
Certifications
• CE
• IC
• CB
• RoHS
• REACH
• WEEE
• RCM
• UKCA
• LOA
