Key Features
- 8 Channel IP Camera Input
- Built-in 8 Port PoE Switch
- Supports Up to 12MP Recording Resolution
- Ultra 265, H.265 and H.264 Compression
- 80Mbps Incoming & Outgoing Bandwidth
- HDMI 4K and VGA Video Output
- ONVIF Profile S, G & T Compatible
- Supports ANR (Automatic Network Replenishment)
- Intelligent AI Search Functions
- Face Detection & Vehicle Detection Support
- Smart Intrusion Prevention (SIP)
- Ultra Motion Detection (UMD)
- People Counting & Heat Map Analytics
- Supports Up to 10TB SATA HDD
- Remote Access via Web Browser and Mobile App
- Plug & Play Camera Installation
- Cloud Upgrade Support
- Datasheet
Video & Recording
Camera Channels: 8 IP Channels
Recording Resolution: Up to 12MP
Compression: Ultra 265, H.265, H.264
Playback Channels: Up to 16 Channels Simultaneously
Incoming Bandwidth: 80Mbps
Outgoing Bandwidth: 80Mbps
Smart Analytics
Face Detection
Vehicle Detection
Intrusion Detection
Cross Line Detection
Enter Area Detection
Leave Area Detection
Ultra Motion Detection (UMD)
People Counting
Crowd Density Monitoring
Traffic Monitoring
Heat Map Analysis
Human, Vehicle and General Search Functions
Video Output
HDMI Output: Up to 4K (3840 × 2160) @ 30Hz
VGA Output: Up to 1920 × 1080 @ 60Hz
Simultaneous HDMI and VGA Output Supported
Audio
Audio Compression: G.711A / G.711U
Audio Input: 1 Channel RCA
Audio Output: 1 Channel RCA
Two-Way Audio Support
Network
Protocols Supported:
TCP/IP, IPv4, IPv6, DHCP, HTTPS, HTTP, RTSP, DDNS, SMTP, SNMP, NTP, PPPoE, P2P
Remote Users: Up to 128
Storage
HDD Bays: 1 SATA Interface
Maximum Capacity: Up to 10TB per HDD
PoE
PoE Ports: 8 x RJ45 10/100Mbps
PoE Standards: IEEE 802.3af / 802.3at
Maximum Per Port Power: 30W
Total PoE Budget: 75W
Interfaces
1 x HDMI Output
1 x VGA Output
1 x RJ45 Network Port
8 x PoE Camera Ports
1 x RCA Audio Input
1 x RCA Audio Output
1 x USB 2.0
1 x USB 3.0
Power
Power Supply: DC 52V / 1.8A
Power Consumption (Without HDD): ≤12W
Environmental
Operating Temperature: -10°C to +55°C
Operating Humidity: ≤90% RH (Non-Condensing)
Physical
Dimensions: 260 × 222 × 47mm
Weight (Without HDD): ≤2.7kg
Form Factor: 1U
Certifications
CE
FCC
UL
RoHS
WEEE
